GTE9021

Material :
RAMIE PACKING COATED WITH GREASE

Brand :

GTE



Structure : Low frictional characteristics & rot resistant, ideal
for marine use.

Categories: , ,

* Shape

* Dimensions-round













* Dimensions-square













* Package-size



* Quantity

Length (Meters) - Optional

Share On

GTE 9021 Ramie Fiber With Grease Impregnated

Application : This medium hard packing is grease lubricated, with extremely low frictional characteristics, where minimum shaft wear is essential. Generally utilized at marine industries, cold water, brine and cold pressed oils.

Dimension Spesification

Size Length PER KG’sLength 2KGLength 5KG
3 mm61122305
6 mm19,238,496
8 mm11,823,659
10 mm7,615,238
12 mm5,410,827
14 mm4820
16 mm3,16,215,5
19 mm2,24,411
22 mm1,73,48,5
25 mm1,32,66,5
30 mm125
38 mm0,61,23
 MetersMetersMeters
P [bar]

To 15 bar (rotating) | To 15 bar (reciprocating) | To 20 bar (static)

pH

6 – 8

Speed

To 6 m/s

Temperature

-30°C To + 80°C
