GTE2600

Material :
FIBERGLASS BRAIDED ROPE PACKING IS MADE FROM 100% NON-ASBESTOS FIBERGLASS YARNS. IT IS LIGHT-WEIGHT, EXTREMELY ROBUST AND HAS LOW THERMAL CONDUCTIVITY. FIBERGLASS ROPE HAVE EXCELLENT HEAT STABILITY UNDER VARIOUS TYPES OF CONDITIONS.

Brand :

GTE



Fiberglass braided rope packing is made from 100% Non-asbestos fiberglass yarns. It is light Weight,high in strength and has low thermal Conductivity. Fiberglass rope have excellent heat Stability under various types of conditions

Structure : Made by inorganic flexible fiberglass fibers, twisted together to form desired cross section. Henceforth ropes of required sizes (in round or square section) are manufactured by interlock braiding technology, and tension are adjusted in machine to obtain desire tightness in ropes.

* Shape

* Dimensions-round













* Dimensions-square













* Package-size



* Quantity

Length (Meters) - Optional

Share On

Technical Data Sheet

GTE2600

FIBERGLASS BRAIDED ROPE PACKING IS MADE FROM 100% NON-ASBESTOS FIBERGLASS YARNS. IT IS LIGHT-WEIGHT, EXTREMELY ROBUST AND HAS LOW THERMAL CONDUCTIVITY. FIBERGLASS ROPE HAVE EXCELLENT HEAT STABILITY UNDER VARIOUS TYPES OF CONDITIONS.

Made by inorganic flexible fiberglass fibers, twisted together to form desired cross section. Henceforth ropes of required sizes (in round or square section) are manufactured by interlock braiding technology, and tension are adjusted in machine to obtain desire tightness in ropes.

Widely used in various applications such as: processing vessels, tanks, grooves,furnace doors, covers, ovendoors, flanges in sheet metal & steel fabricating industries etc.

Construction  :    Filament Made By Inorganic Flexible Fiberglass Fibers

Temperature  :    Max 600°C

pH Range       :    3 – 14

Shaft Speed   :    1 m/s

Pressure          :    Max 40 Bar

P [bar]

Max 40 Bar

pH

3 -14

Speed

1 m/s

Temperature

Max 600°C
