GTE9046

Material :
HIGH STRENGTH GRAPHITE YARN, IMPREGNATED WITH PTFE DISPERSION. BRAIDED BY HIGH STRENGTH PTFE FILLAMENT YARN WITH GRAPHITE IMPREGNATION. THE CHARACTERISTICS ARE SIMILAR TO “CGFO”

Merk :

GTE



Struktur :Pengemasan mengandung lebih banyak konten grafit dibandingkan dengan PTFE normal, karakteristiknya mirip dengan GFO, memiliki kepadatan penampang, dan beberapa partikel grafit di permukaan memiliki kualitas pelumas serat grafit PTFE

Kategori , , Tag: ,

* Shape

* Dimensions-round













* Dimensions-square













* Ukuran paket



* Kuantitas

Panjang (Meter) - Opsional

Bagikan Pada
Download TDS

Technical Data Sheet

GTE9046

HIGH STRENGTH GRAPHITE YARN, IMPREGNATED WITH PTFE DISPERSION. BRAIDED BY HIGH STRENGTH PTFE FILLAMENT YARN WITH GRAPHITE IMPREGNATION. THE CHARACTERISTICS ARE SIMILAR TO “CGFO”.

The packing contains more graphite content compared with normal PTFE, the characteristics are similar to GFO, has cross-sectional density, and some particles of graphite on surface has lubricating qualities of the PTFE graphite fiber.

Recommended for application on the shaft working in direct contact with any chemical elements.

Construction  :    PTFE Graphite Fiber Packing

Temperature  :    -100°C To + 280°C

pH Range       :    0 – 14

Shaft Speed   :    To 20 m/s

Pressure          :  To 30 bar (rotating)

                             To 100 bar (reciprocating)

                             To 150 bar (static)

P [batang]

20 Bar
pH

4 – 12
Kecepatan

16 m/s
Suhu

Max 260° C
Ukuran paket

2 KG, 5 KG
